Corrosion Resistant FRP Grating - Fiberglass Grate Applications & Drainage

5 0 Reviews

Length: The standard length for fiberglass grating panels is 1200mm, with a customizable range of 500–3000mm to fit your project.
Width: Common widths for fiberglass grating are 600mm and 900mm, with a customizable range of 300–1500mm.
Thickness: Fiberglass grating panels come in multiple thickness options, including 30mm, 38mm, and 50mm.

Quantity:
Availability:





Inquire Add to Basket

Brand:
JunHe

Product Description

Advantages

Exceptional Corrosion Resistance

Unlike traditional metal grating, fiberglass grating is naturally resistant to rust and corrosion. This makes it a top-notch option for environments such as chemical plants and wastewater treatment facilities, where coming into contact with corrosive substances is a regular occurrence—solidifying its status as a reliable corrosion resistant fiberglass grating.

Remarkable Strength

Fiberglass grating offers outstanding strength properties. Made with high-quality glass fibers, this heavy duty fiberglass grating delivers impressive load-bearing capacity—specifically, it can support up to 3000 pounds per square foot. This makes it highly suitable for applications like industrial walkways and platforms, where long-term durability of fiberglass grating panels is a must-have.

Superior Chemical Resistance

FRP grating (fiberglass reinforced plastic grating) shows excellent resistance to a wide range of chemicals, including acids and alkalis. Laboratory tests have proven that fiberglass grating remains undamaged after being immersed in a 10% sulfuric acid solution for more than 1000 hours—making it an ideal choice for chemical plants and wastewater treatment facilities in need of practical fiberglass grating solutions.

Slip-Resistant Design

Non-slip fiberglass grating has a surface designed for slip resistance. Its textured finish results in a friction coefficient as high as 0.6, which greatly reduces the risk of slips and falls. This feature is particularly vital in safety-critical areas like stair treads and walkways in wet conditions, where non-slip fiberglass grating is indispensable.

Lightweight and Durable

Lightweight fiberglass grating is easy to handle yet highly durable. When compared to a steel grating of the same specifications, this fiberglass grate weighs only a quarter as much, while its service life can exceed 20 years. This combination of light weight and durability simplifies the installation of fiberglass grating panels and provides long-term cost-effectiveness.

Customizable to Fit Specific Needs

Fiberglass grating provides a high degree of design flexibility, allowing you to create tailored fiberglass grating solutions. It can be customized into different sizes and shapes to meet the specific requirements of a project—whether it’s a circular opening or a uniquely shaped platform—ensuring a perfect fit for your fiberglass grating application.

Detailed Parameter Overview

Dimension Specifications

Length: The standard length for fiberglass grating panels is 1200mm, with a customizable range of 500–3000mm to match your project needs.
Width: Common widths for fiberglass grating are 600mm and 900mm, with a customizable range of 300–1500mm.
Thickness: Fiberglass grating panels are available in multiple thickness options, including 30mm, 38mm, and 50mm.

Load-Bearing Capacity

Uniform Load: For fiberglass grating, the uniform load ranges from 3000–5000N/m², depending on its thickness and structure—ideal for heavy duty fiberglass grating applications.
Concentrated Load: The single-point concentrated load for FRP grating can reach 1000–2000N, supporting high-demand use cases.

Grating Spacing

Crossbar Spacing: Typically 30mm and 40mm for fiberglass bar grating, ensuring stable performance.
Longitudinal Bar Spacing: Common values are 40mm and 50mm, suitable for both narrow opening fiberglass bar grating and standard designs.

Material Properties

Glass Fiber Content: No less than 70% for high-quality FRP grating and fiberglass grating.
Resin Type: Includes unsaturated polyester resin, vinyl ester resin, and other options for manufacturing durable fiberglass grating.
Tensile Strength: No less than 500MPa for reliable fiberglass grate performance.
Bending Strength: No less than 700MPa for sturdy FRP grating applications.

Surface Treatment

Anti-slip Treatment: Non-slip fiberglass grating features a granular anti-slip layer with a friction coefficient of at least 0.6.
Coating Treatment: An anti-corrosion coating can be applied to corrosion resistant fiberglass grating, with a salt spray test time of at least 1000 hours.

Fire-Resistant Performance

Fire-Retardant Grade: Fiberglass grating panels achieve the UL94-V0 level (flame-retardant grade) for enhanced safety.

Applications

Industrial Platforms

In factory workshops, fiberglass grating panels are widely used to construct operating platforms. This heavy duty fiberglass grating can support equipment and workers during operations, while its corrosion-resistant properties allow it to withstand chemical substances in the industrial environment—ensuring the long-term stable operation of the platform and improving work safety and efficiency.

Building Stairs

Non-slip fiberglass grating is also used in building stairs. Its slip-resistant surface effectively reduces the risk of slipping. As lightweight fiberglass grating, it simplifies installation, lowering construction difficulty and costs. Additionally, its aesthetic appeal and durability make it suitable for various architectural styles.

Sewage Treatment Facilities

In sewage treatment plants, fiberglass grating drainage and drainage fiberglass grating are used for gratings and walkways. This corrosion resistant fiberglass grating can perform well in the highly corrosive sewage environment, ensuring the long-term reliable operation of the facilities.

Power Industry Maintenance Walkways

In power substations and other locations, FRP grating is often used for maintenance walkways. This fiberglass grating is insulating and has high strength, guaranteeing the safety of maintenance personnel. Even in severe weather conditions, it can stably support the weight of people walking on it.

Offshore Operation Platforms

The offshore environment is extremely harsh, but fiberglass grating is well-suited for use on offshore operation platforms. As a professional fiberglass grating supplier and fiberglass grating manufacturer, our products resist seawater corrosion and ultraviolet rays, can withstand the impact of ocean waves and the heavy pressure of equipment, and provide a safe and stable working space for offshore operations—including high-quality fiberglass catwalk grating solutions.

FAQ：

1. What is the lifespan of FIBERGLASS GRATING?

Under normal conditions, its lifespan can reach over 20 years. This is due to its corrosion - resistant materials and stable structure, ensuring long - term use without significant degradation.

2. Can FIBERGLASS GRATING be customized?

Absolutely. We offer customization services. You can tell us your specific requirements regarding size, shape, and surface treatment. Our team will tailor the product to meet your needs precisely.

3. How do you ensure the quality of FIBERGLASS GRATING?

We have strict quality control processes. Raw materials are carefully selected, and each production step is monitored. Products undergo multiple tests, like load - bearing and corrosion resistance tests, to guarantee high - quality output.
