Exceptional Corrosion Resistance: A thick zinc layer forms on the surface through hot-dipping, preventing rust and corrosion. It maintains durability for over 20 years outdoors, making it ideal for chemical plants and coastal regions.
High Strength and Load Capacity: Constructed with quality steel bars in an optimized arrangement, standard models can bear 3-5 tons per square meter. Suitable for heavy-duty industrial environments and traffic areas.
Excellent Slip Resistance: Unique surface patterns enhance friction with a slip resistance coefficient exceeding 0.6, preventing slips on wet or dusty walkways and stair treads.
Easy Installation and Low Maintenance: Pre-fabricated design allows quick installation via bolts or welding, saving time and labor. Requires minimal upkeep—only occasional inspections—reducing long-term costs.
Superior Quality and Customization: Our factory implements strict quality control, with every batch undergoing rigorous inspection to ensure top quality. We offer customization of size, shape, and load capacity to meet requirements of projects of all scales.
Materials: Available in Q235 low-carbon steel (offering good overall mechanical properties at an affordable price) or stainless steel (304, 316, etc., providing excellent corrosion resistance for special environments).
Dimensions (Load-Bearing Flat Bar × Cross Bar): Common load-bearing flat bar sizes include 20×5, 25×5, 30×3, 30×5, 40×5, 50×5 mm (and others). Typical cross bar sizes are 5×5, 6×6, 8×8 mm (and more). Different combinations accommodate various load requirements.
Mesh Sizes: Frequently used options include 30×100, 40×100, 60×100 mm (and others). Smaller meshes suit high-safety applications (preventing small objects from falling), while larger meshes prioritize ventilation and drainage with lower costs.
Galvanized Layer Thickness: After hot-dipping, average thickness is at least 85μm, with local thickness no less than 70μm. Meets national standards to ensure corrosion resistance and extend service life.
Load Capacity: Varies by specification. For example, the 303/30/100 model supports a uniform load of 3.5kN/m² and concentrated load of 3.85kN. Select appropriate specifications based on actual load requirements.
Surface Treatment: Primarily uses hot-dip galvanization to form a uniform, dense zinc layer, significantly enhancing corrosion resistance. Other options (cold galvanization, painting) available upon request.
FAQ：
Q: How long can the hot - dipped galvanized steel grating last?
A: In normal outdoor conditions, it can last over 20 years due to the thick anti - corrosion zinc layer. But lifespan may vary in special environments like chemical plants.
Q: Can the steel grating be customized?
A: Absolutely. We can customize the size, shape, and load - bearing capacity according to your needs. Just let us know your specific requirements.
Q: What's the installation process like?
A: It's quite simple. First, align the grating accurately. Then, secure it using bolts or welding. Installation time is short, saving you both time and labor costs.
Q: How to maintain the hot - dipped galvanized steel grating?
A: Maintenance is easy. Just conduct occasional inspections. Since it has high corrosion resistance, there's no need for frequent upkeep. Only repair if any damage is found.
