Exceptional Corrosion Resistance
By undergoing hot-dip galvanization, a robust zinc layer is formed on the surface, effectively preventing rust and corrosion. This makes it suitable for outdoor use lasting over 20 years, particularly ideal for chemical plants and coastal regions.
High Strength & Heavy Load Capacity
Constructed from premium-quality steel bars with an optimized bar combination, a standard type can support loads ranging from 3 to 5 tons per square meter. It is well-suited for heavy-duty industrial and high-traffic areas.
Superior Anti-Slip Performance
The unique surface patterns enhance friction, with an anti-slip coefficient exceeding 0.6. This helps prevent slips on wet or dusty walkways and stair treads, ensuring safety.
Simple Installation & Low Maintenance
Pre-fabricated for quick and easy installation using bolts or welding, it saves both time and labor. Minimal maintenance is required, with only occasional checks needed to reduce long-term costs.
Premium Quality & Highly Customizable
Our factory adheres to strict quality control measures. Every batch of steel grating undergoes thorough inspection to ensure top-notch quality. Additionally, we offer customization in terms of size, shape, and load-bearing capacity to meet specific customer requirements, providing solutions for projects of all sizes.
Material: Utilizes Q235 low-carbon steel, known for its good overall mechanical properties and affordability, or stainless steel (such as 304 and 316), which offers excellent corrosion resistance for special environments.
Specification (Load-bearing Flat Bar × Cross Bar):
Common load-bearing flat bar sizes include 20×5, 25×5, 30×3, 30×5, 40×5, 50×5 mm, etc.
Common cross bar sizes are 5×5, 6×6, 8×8 mm, etc.
Various combinations of these specifications can cater to different load-bearing needs.
Mesh Size:
Frequently used mesh sizes are 30×100, 40×100, 60×100 mm, etc.
Smaller mesh sizes are suitable for areas requiring high safety protection to prevent small objects from falling.
Larger mesh sizes are more cost-effective and focus on functions like ventilation and drainage.
Galvanized Layer Thickness:
After hot-dip galvanization, the average thickness of the galvanized layer is no less than 85μm, with local thickness no less than 70μm.
This thickness complies with national standards, effectively ensuring the product's corrosion resistance and extending its service life.
Bearing Capacity:
Varies depending on the specification. For instance, the 303/30/100 specification steel grating can support a uniform load of up to 3.5kN/m² and a concentrated load of up to 3.85kN.
Select the appropriate specification based on the actual load requirements of the usage scenario.
Surface Treatment:
The primary surface treatment is hot-dip galvanization, which forms a uniform and dense zinc layer on the steel grating's surface, significantly enhancing its corrosion resistance.
Other surface treatments, such as cold galvanization and painting, can also be performed according to customer needs.
Before installation, verify the size and quality of the hot-dipped galvanized steel grating. During installation, align the grating accurately and secure it firmly using bolts or welding. When using in high-load areas, ensure that the load does not exceed its capacity. Regularly inspect for any signs of damage or corrosion. Following these simple steps ensures the long-term and safe use of the steel grating.
FAQ：
Q: How long can the hot - dipped galvanized steel grating last?
A: In normal outdoor conditions, it can last over 20 years due to the thick anti - corrosion zinc layer. But lifespan may vary in special environments like chemical plants.
Q: Can the steel grating be customized?
A: Absolutely. We can customize the size, shape, and load - bearing capacity according to your needs. Just let us know your specific requirements.
Q: What's the installation process like?
A: It's quite simple. First, align the grating accurately. Then, secure it using bolts or welding. Installation time is short, saving you both time and labor costs.
Q: How to maintain the hot - dipped galvanized steel grating?
A: Maintenance is easy. Just conduct occasional inspections. Since it has high corrosion resistance, there's no need for frequent upkeep. Only repair if any damage is found.
Exceptional Corrosion Resistance
By undergoing hot-dip galvanization, a robust zinc layer is formed on the surface, effectively preventing rust and corrosion. This makes it suitable for outdoor use lasting over 20 years, particularly ideal for chemical plants and coastal regions.
High Strength & Heavy Load Capacity
Constructed from premium-quality steel bars with an optimized bar combination, a standard type can support loads ranging from 3 to 5 tons per square meter. It is well-suited for heavy-duty industrial and high-traffic areas.
Superior Anti-Slip Performance
The unique surface patterns enhance friction, with an anti-slip coefficient exceeding 0.6. This helps prevent slips on wet or dusty walkways and stair treads, ensuring safety.
Simple Installation & Low Maintenance
Pre-fabricated for quick and easy installation using bolts or welding, it saves both time and labor. Minimal maintenance is required, with only occasional checks needed to reduce long-term costs.
Premium Quality & Highly Customizable
Our factory adheres to strict quality control measures. Every batch of steel grating undergoes thorough inspection to ensure top-notch quality. Additionally, we offer customization in terms of size, shape, and load-bearing capacity to meet specific customer requirements, providing solutions for projects of all sizes.
Material: Utilizes Q235 low-carbon steel, known for its good overall mechanical properties and affordability, or stainless steel (such as 304 and 316), which offers excellent corrosion resistance for special environments.
Specification (Load-bearing Flat Bar × Cross Bar):
Common load-bearing flat bar sizes include 20×5, 25×5, 30×3, 30×5, 40×5, 50×5 mm, etc.
Common cross bar sizes are 5×5, 6×6, 8×8 mm, etc.
Various combinations of these specifications can cater to different load-bearing needs.
Mesh Size:
Frequently used mesh sizes are 30×100, 40×100, 60×100 mm, etc.
Smaller mesh sizes are suitable for areas requiring high safety protection to prevent small objects from falling.
Larger mesh sizes are more cost-effective and focus on functions like ventilation and drainage.
Galvanized Layer Thickness:
After hot-dip galvanization, the average thickness of the galvanized layer is no less than 85μm, with local thickness no less than 70μm.
This thickness complies with national standards, effectively ensuring the product's corrosion resistance and extending its service life.
Bearing Capacity:
Varies depending on the specification. For instance, the 303/30/100 specification steel grating can support a uniform load of up to 3.5kN/m² and a concentrated load of up to 3.85kN.
Select the appropriate specification based on the actual load requirements of the usage scenario.
Surface Treatment:
The primary surface treatment is hot-dip galvanization, which forms a uniform and dense zinc layer on the steel grating's surface, significantly enhancing its corrosion resistance.
Other surface treatments, such as cold galvanization and painting, can also be performed according to customer needs.
Before installation, verify the size and quality of the hot-dipped galvanized steel grating. During installation, align the grating accurately and secure it firmly using bolts or welding. When using in high-load areas, ensure that the load does not exceed its capacity. Regularly inspect for any signs of damage or corrosion. Following these simple steps ensures the long-term and safe use of the steel grating.
FAQ：
Q: How long can the hot - dipped galvanized steel grating last?
A: In normal outdoor conditions, it can last over 20 years due to the thick anti - corrosion zinc layer. But lifespan may vary in special environments like chemical plants.
Q: Can the steel grating be customized?
A: Absolutely. We can customize the size, shape, and load - bearing capacity according to your needs. Just let us know your specific requirements.
Q: What's the installation process like?
A: It's quite simple. First, align the grating accurately. Then, secure it using bolts or welding. Installation time is short, saving you both time and labor costs.
Q: How to maintain the hot - dipped galvanized steel grating?
A: Maintenance is easy. Just conduct occasional inspections. Since it has high corrosion resistance, there's no need for frequent upkeep. Only repair if any damage is found.
