JunHe
Load-Bearing Flat Steel: We offer Q235A carbon steel as a budget-friendly yet strong option, or stainless steel (304/316) for better corrosion resistance.
Cross Bar: You can choose Q235A or 304 stainless steel. The cross bars can be round, twisted square (ranging from 5×5mm to 8×8mm), square, or hexagonal—all designed to boost stability.
Flat Steel: Thickness ranges from 3–10mm (e.g., 25×3mm to 100×10mm), and the width depends on load demands.
Grid: The center-to-center distance of flat steel can be 30/40/60mm; the cross-bar spacing is 100/50mm.
Overall: We have standard sizes available, and customization is also possible. The standard width is 995mm, with a 5mm gap for installation.
Light-Duty: Can bear 25 tons per square meter, fitting for residential walkways, parks, and parking areas for light vehicles.
Medium-Duty: Rated for 70 tons per square meter, ideal for factory areas and regular roads where vehicles weigh less than 20 tons.
Heavy-Duty: Capable of bearing 140 tons per square meter, designed for high-traffic areas like main roads and industrial docks.
Hot-Dip Galvanizing: Has an 85μm zinc coating, ensuring a service life of over 20 years under normal conditions.
Cold Galvanizing: Provides a thin coating, suitable for applications with lower requirements.
Painting: Uses anti-rust paint in different colors, which not only improves appearance but also prevents corrosion.
Leakage Area: Up to 83.3%, allowing fast water drainage.
Example: When rainfall reaches 50mm per hour, it can drain 1,000 liters of water per minute per square meter.
Q: What's the lifespan of the steel grilles?
A: Our steel grilles, especially when hot - dip galvanized, can last over 20 years in normal conditions. Their robust material ensures long - term durability against wear and corrosion.
Q: Are they easy to install?
A: Yes. Standard - sized grilles come with a 5 - mm installation gap for easy fitting. They can be quickly placed in position. Custom - sized ones also have straightforward installation procedures.
Q: How to clean the grilles?
A: Regularly remove debris with a broom or shovel. For stubborn dirt or stains, use a mild detergent and water. In industrial settings, power - washing may be needed to handle heavy - duty grime.
Q: Can the grilles bear heavy loads?
A: Absolutely. They're designed with different load - bearing capacities. Heavy - duty grilles can withstand up to 140 tons/m², suitable for areas with heavy - truck traffic.
Q: Do you offer customization?
A: Yes, we provide customization in terms of size, shape, and hole patterns. This allows the grilles to meet specific project requirements, whether for aesthetics or functionality.
