Fiberglass grating is a type of flooring material made from a composite of fiberglass and resin. It is designed to provide a strong, lightweight, and corrosion-resistant surface.
Commonly used in industrial and commercial applications, fiberglass grating offers several benefits.
Corrosion Resistance
Unlike traditional metal grating, fiberglass is inherently resistant to rust and corrosion, making it an ideal choice for chemical plants, wastewater.
High Strength
Fiberglass grating features outstanding strength. Manufactured with high - quality glass fibers, it has an excellent load - bearing capacity. Specifically, it can bear up to 3000 pounds per square foot. This characteristic makes it perform remarkably well in applications such as industrial walkways and platforms, ensuring long - term durability.
Chemical Resistance
The grating demonstrates excellent chemical resistance. It can resist a wide range of chemicals, including acids and alkalis. In laboratory tests, it remained intact after being immersed in a 10% sulfuric acid solution for over 1000 hours. This property makes it an ideal choice for chemical plants and wastewater treatment facilities.
Slip - Resistant Surface
The grating is designed with a slip - resistant surface. Its surface texture results in a friction coefficient as high as 0.6, significantly reducing the risk of slips and falls. This feature is crucial for safety - sensitive areas such as stair treads and wet - area walkways.
Lightweight yet Durable
Fiberglass grating is lightweight yet highly durable. Compared with a steel grating of the same specification, it weighs only one - fourth as much, while its service life can exceed 20 years. This perfect combination of light weight and durability simplifies the installation process and is highly cost - effective in the long run.
Customizable Design
It offers a customizable design. The grating can be tailored to different sizes and shapes according to specific project requirements. Whether it's a circular opening or a uniquely shaped platform, this design flexibility ensures a perfect fit.
Dimension Specification
Length: The standard length is 1200mm, and the customizable range is 500 - 3000mm.
Width: Common widths are 600mm and 900mm, and the customizable range is 300 - 1500mm.Thickness: Multiple thickness options such as 30mm, 38mm, and 50mm are available.
Load - bearing Capacity
Uniform Load: 3000 - 5000N/m² (varies according to different thicknesses and structures)
Concentrated Load: The single - point concentrated load can reach 1000 - 2000N
Grating Spacing
Crossbar Spacing: Usually 30mm and 40mmLongitudinal
Bar Spacing: Common ones are 40mm and 50mm
Material Properties
Glass Fiber Content: ≥70%
Resin Type: Unsaturated polyester resin, vinyl ester resin, etc.
Tensile Strength: ≥500MPa
Bending Strength: ≥700MPa
Surface Treatment
Anti - slip Treatment: The surface has a granular anti - slip layer with a friction coefficient ≥0.6
Coating Treatment: An anti - corrosion coating can be provided, and the salt spray test time ≥1000 hours
Fire - resistant Performance
Fire - retardant Grade: Reaches UL94 - V0 level (flame - retardant grade)
Industrial Platforms
In factory workshops, FIBERGLASS GRATING is widely used to build operating platforms. Its high strength can support equipment and workers during operations, and its corrosion - resistant property can withstand chemical substances in the industrial environment, ensuring the long - term stable operation of the platform and improving work safety and efficiency.
Building Stairs
FIBERGLASS GRATING is used in building stairs. Its slip - resistant surface can effectively reduce the risk of slips. The lightweight feature facilitates installation, reducing construction difficulty and cost. Meanwhile, its aesthetic appearance and durability make it suitable for various architectural styles.
Sewage Treatment Facilities
In sewage treatment plants, FIBERGLASS GRATING is used for gratings and walkways. Its excellent acid and alkali resistance enables it to function properly in a highly corrosive sewage environment, ensuring the long - term reliable operation of the facilities.
Power Industry Maintenance Walkways
In power substations and other places, FIBERGLASS GRATING is often used for maintenance walkways. It is insulating and has high strength, ensuring the safety of maintenance personnel. Even in severe weather conditions, it can stably bear the weight of people walking.
Offshore Operation Platforms
The offshore environment is harsh, and FIBERGLASS GRATING is used on offshore operation platforms. It is resistant to seawater corrosion and ultraviolet rays, and can withstand the impact of ocean waves and the heavy pressure of equipment, providing a safe and stable working space for offshore operations.
1. What is the lifespan of FIBERGLASS GRATING?
Under normal conditions, its lifespan can reach over 20 years. This is due to its corrosion - resistant materials and stable structure, ensuring long - term use without significant degradation.
2. Can FIBERGLASS GRATING be customized?
Absolutely. We offer customization services. You can tell us your specific requirements regarding size, shape, and surface treatment. Our team will tailor the product to meet your needs precisely.
3. How do you ensure the quality of FIBERGLASS GRATING?
We have strict quality control processes. Raw materials are carefully selected, and each production step is monitored. Products undergo multiple tests, like load - bearing and corrosion resistance tests, to guarantee high - quality output.
